1x2 1x4 1x8 1x16 1x32 PLC Fiber Splitter Steel Tube Bare 250um No Connector | Мобильные телефоны и аксессуары

Features

*Excellent Mechanical,Small Size

*High Reliability

*Low insertion Loss and low Polarization Dependent loss

*High channel counts

*Excellent Environmental Stability and Widely Used



Applications

*FTTx Deployments(GPON/BPON/EPON)

*Cable television (CATV)

*Local area networks (LAN)

*Test equipment

*Passive optical networks(PON)



Specifications

  1 1xN (with connector) (Number   of Channels) 1×2 1×4 1×8 1×16 1×32 1×64 2×2 2×4 2×8 2×16 2×32 2×64 (Operating   Wavelenth) 1260 to 1650   P   Level Insertion Loss 4 7.4 10.5 13.7 17 20.3 4.4 7.6 10.8 14.1 17.4 20.7 S   Level Insertion Loss 4.2 7.6 10.7 14 17.3 20.7 4.6 7.9 11.2 15 18.1 21.7 (Uniformity) 0.4 0.6 0.8 1 1.2 1.6 0.8 1 1.2 1.5 1.8 2 (PDL) 0.2 0.3 0.3 0.3 0.3 0.5 0.3 0.3 0.3 0.3 0.3 0.5 (Return   Loss) more than 55 (Directivity) more than 55 (Type   of fiber) ITU   G657A (Operating   temperature) -40 to 85 (Pigtail   length) 1m or 1.5m   or customized



Factory show

Packing & Delivery If you have any query, please click below. Best service and best factory price is wating for you...
