Kebidu 433Mhz Cloning Wireless Remote Control RF Transmitter Copy for Electric Gate Garage Door Auto Keychain Universal | Электроника

Kebidu 433Mhz Cloning Wireless Remote Control RF Transmitter Copy for Electric Gate Garage Door Auto Keychain Universal | Электроника

Use range:

The copyable chip model has a learning range:

1. HT-12E, 2. AX5326-3, 3. AX5326-4, 4. AX5026, 5. PT2262, 6. PT2242, 7. HT600, 8. HT680, 9. HT6207, 10. HT6010, 11. HT6012 12. HT6014, 13. MC145026, 14. HT640, 15.EV1527, 16.527, 17.PT2260, 18.SMC918, 19.SMC926, 20.HT12D, 21.PT2240B

(Note: If your original remote control's chip is not as listed above, you can contact us to check whether it can copy or not.)

Duplication and regeneration of wireless remote controls for barriers, garage doors, etc.

The scope of application of copy remote control:

Ordinary fixed code (chip type 2260, 2262, 2264), learning code (1527, 2240) remote control.

technical parameter:

Product name: 433Mhz/315Mhz four-button copy remote control

Working voltage: 6V

Encoding type: copy, copy

Working frequency: 433Mhz/315Mhz

Number of keys: four keys

Operation method:

1. Code pairing

Place the original remote control and the copy remote control as close as possible, first press a button of the original remote control, and immediately after the indicator light turns on, press and hold a button of the self-copy remote control for about three seconds, the LED will flash 3 times and then quickly Flashing, it means that the address code of the original remote control button has been learned successfully. The other keys are operated in the same way for learning.

2, clear code

Press the unlock button and the lock button at the same time for 2 seconds, the LED light will start to flash 3 times. At this time, keep the lock button pressed and release the unlock button. Press the unlock button three or four times within 5 seconds, and the indicator light flashes quickly, which indicates The code has been cleared.

Test whether the existing code of the remote control has been successfully cleared: When you finish the clearing action, you can press any button of the copy remote control. If the LED does not flash immediately at this time, it will flash after 2 seconds, that means The original code of the copied remote control has been completely cleared. If the LED still flashes quickly and immediately, the code still exists and needs to be cleared again.

3, restore the cleared code

The copy remote control has a recovery function. If you accidentally clear the address code of the normal copy remote control during use, you can press the start and mute buttons (the next two buttons) on the remote control at the same time. After about three seconds, the LED will flash 3 times. It starts to flash quickly, which means that the cleared address code is successfully restored.

*Precautions:

1. Before using our copy remote control to copy, first clear the existing code of the self-copy remote control.

2. The self-copy remote control cannot copy the rolling code, such as HCS301.
