Welding mask resanta MS-6 is designed to protect the eyes from visible, ultraviolet and infrared radiation, as well as to protect the head and neck from getting Sparks during welding. The mask of this type is convenient, because the filter is automatically darkened when the arc is lit. Such a filter was called "chameleon" due to the ability to automatically darken. The degree of dimming can be adjusted using the built-in regulator depending on the model of the mask.

Resanta MS-6-a budget model in the line of masks of the manufacturer resant. Powered by solar battery, ideal for household use.

Features and Benefits

Filter
The light filter of welding masks resant has a structure of a puff pie. The first layer is a protective screen designed to protect the inner layers from mechanical damage. Then there are several layers of liquid crystals, alternating with polarizing films, to protect the eyes from bright visible radiation. And finally, the last layer goes ultraviolet and infrared filter, which almost completely absorbs ultraviolet and infrared radiation.

Automatic light filter of resant masks
For welding masks MS-1, MS-2, MS-3:
-External dimming regulator, as well as switching to grinding mode "Grind" (depending on the model)
-Internal sensitivity adjustment
-Internal adjustment of delay time
In the automatic light filter masks MS-2, MS-3, MS-5 there is a replaceable battery supply (located under a special cover).
Automatic filter for masks ms-4 and MS-6 without adjustments.

Adjustment of modes of welding masks resanta
-Adjustment of "degree of dimming". Allows you to adjust the degree of dimming depending on the brightness of the welding arc.
-Adjustment of "sensitivity". The optical sensor sensitivity adjustment function allows you to set the desired mode depending on welding modes. With high sensitivity, the darkening will produce from less bright flashes (for models MS-1, MS-2, MS-3, MS-5).
-Adjustment of "clearance delay" allows you to adjust the transition time from the dark state to the light: the welder can adjust the filter return time to the light state (for ms-s-1
-Mode "grinding". In this mode, the mask will protect the operator during grinding work, without changing the bandwidth for light (for models MS-1, MS-2, MS-3, MS-5).

Features:

Brand

Resanta

Type

Welding mask

Screen dimensions, mm

90x35

Type светофильтра

Chameleon

Opening delay, C

0.6

Degree of lightening, Din

4

Degree of dimming, Din

11

Switching time, Ms

1

Adjustment dimming

Inner

Material

Plastic

Type power supply

Solar battery + 2 cr2927 batteries
