 RGBDimmer is a new led strip dimmer controller that can adjust brightness of color (for instance red, green and blue) infinitely.
Its control mode is knob-operated control, you could adjust light to the approriate lighting color in accordance with your actual need.
It will make your life more colorful.

Name of Product: RGB Dimmer Stepless Adjustable Switch
Input Voltage: DC12-24V
Wattage: 12v<108W, 24v<216W
Output: 3 channels
Connection Mode: common anode
External dimension: L130 * W40 * H52 mm
Static Oower Consumption: < 1W
Output current: 3A each channel
Working temperature: -20-60

2. Direction for use
Connect the Load wire at first, following by the power wire. Please ensure short circult can net occur betwwen connecting
wire before you turn on the power.
Adopt rotary button, it\'s function as follows:
Rotate button to the right, brightness will be brighter,when you rotate it to the far right, the brightness is greatest.
Rotate button to the left, brightness will be darker,when you rotate it to the far left, the light will be turned off.



Package Included:

1 x RGB Dimmer Stepless Adjustable Switch
