it can install on the Chademo ev charging station to charging all the chademo standard electric vehicles, such as the chademo plug

Features

1- Thechademo plugwith safty pins insulated head design to prevent accidental dirrect contact with staff.

3-Thechademo plugcan install on the fast ev charging station as electric outlet to charging the electirc cars.

Basic Data

Electric Performance.

Rated current

125A / 150A /200A option

Operate voltage

1000V DC

Standard

IEC 62196 Standard chademo plug

Mechanical life

no-load plug in / plug out > 10000 times

Materia

Thermoplastic, Flame retardant grade UL94-0;

Pin:Cooper alloy,sliver + thermoplastic on the top

Operation Temp.

-30℃ ~ + 50℃

IP protection class

IP 54

IEC 62196-3 CHAdeMO Ev Plug DC 125A 500V DC Ev charger connector

1.Conform to the provisions and requirements of  IEC 62752,  IEC 61851.
2.Using riveting pressure process with none screw ,have a beautiful appearance. Hand-held design conform to the ergonomic principle , plug conveniently.
3.TPE for cable insulation prolonging the aging resistance  life-span, TPE sheath improved the bending life and wear resistance of ev charging cable.
4.Excellent protection performance, protection grade achieved IP67 (working condition).

Materials
Shell Material: Thermo Plastic ( Insulator inflammability UL94 VO)
Contact Pin: Copper alloy, silver or nickel plating
Sealing gasket: rubber or silicon rubber

TPE insulation,TPE Sheath EV Charging Cable for EV Plug & EV Socket ,32A 240V 62196
