New Original Programmable Controller PLC Module 18 Point NPN Input 14Point Transistor Output XC2-32T-E AC220V | Обустройство дома

New Original Programmable Controller PLC Module 18 Point NPN Input 14Point Transistor Output XC2-32T-E AC220V | Обустройство дома

 Features:

18 DI/14 DO, AC220 or DC24V power supply;

Can be expanded with expansion module, BD board.

Support RTC, power-off retentive;

Support basic logic control and data operation;

Support high speed count, pulse output, exterior interruption, C language function block, free switch for I/O points, free protocol communication and MODBUS communication.

General Specifications

Item

Specification

Insulation Voltage

Above DC 500V 2MΩ

Noise Resistance

1000V 1uS pulse for 1 minute

Environment Temperature

0°C ~60°C

Ambient Humidity

5%~95%

COM 1

RS-232, be connected to host machine or HMI for programming or debugging

COM 2

RS-485/RS-232, network or connect to intelligent instrument, inverter, etc.

COM 3

BD extensional communication port RS-485/RS232

Installation

M3 screw fixed or DIN46277 (35mm width) guide rail installation

Grounding

The third type grounding (Never perform common grounding with strong power system)

Performance:

Item

Specification

Program Operation Mode

Circulation scanning mode, timing scanning mode

Program Mode

Instructions and ladder chart

Dispose Speed

0.5us

Power Failure Holding

FlashROM

User Program's Capacity

128K

I/O Points

18 input points, 14 output points

Output Format

Relay

Power Supply

AC220V/DC24V

Interior Coil's Points (M)

8512 points

Timer(T)

Points

640 points

Specification

100mS timer: set time 0.1~3276.7 seconds

10mS timer: set time 0.01~327.67 seconds

1mS timer: set time 0.001~32.767 seconds

Counter(C)

Points

640 Points

Specification

16 bits counter: Set value K0~32767

32 bits counter: Set value K0~2147483647

Data Register(D)

2512 characters

FlashROM Register(FD)

768 characters

High-speed Count Format

High speed counter, pulse output, exterior interruption

Timing Scanning Interval Setting

0~99mS

Password

6 characters ASCII

Self-diagnose Function

Power on self-diagnose, monitor timer, grammar check
