Offset Asymmetrical Design

Asymmetrical rims build up into stiffer, stronger and more reliable wheels by improving the bracing angles of a dished wheel and equalizing the spoke tensions between the drive and non-drive side spokes. On a Road bike wheelset with disc brakes, both the front and rear wheels have significant dish. With traditional rims,the rim is centered (or dished) by decreasing spoke tension on one side relative to the other so that the rim is pulled into center.

2 years warranty for the rims.

Maybe not the cheapest, but the best quality and after sale service.

Hand-built carbon mountain bike 29er XC asymmetric rims

SHlMANO and Sram XX1 compatible,please tell us which do you want.

If you do not tell us , we will send for SHlMANO

Rim section

Specifications

Set weight

1330g +/- 20g

1420g+/- 20g

Max recommended rider weight

250lbs

Front Wheel

Weight

605g/650g

Rim Used

XCAS01/XCAS02

Hub Used

DT swiss 350S/DT swiss 240S

Rim Depth

25mm

Rim Width

27mm/30mm

Inner Width

22mm/24mm

Skewer type

9mm QR/12x100/15x100/15x110

Spokes

Pillar X-TRA 1420 aero

Sapim cx ray

Spoke Count

28

Spoke Pattern

4 x cross

Spoke Length

290mm

Max Tire Pressure

60psi

Max Tire Pressure

4bars

Track Adaptable

No

Brake Surface

n/a

Nipples

Taiwan CN® alloy nipple

External Nipples

Yes

Rear Wheel

Weight

725g/770g

Hub Used

DT swiss 350S/DT swiss 240S

Rim Used

XCAS01/XCAS02

Rim Depth

25mm

Rim Width

27mm/30mm

Internal Width

21mm/24mm

Spokes

Pillar X-TRA 1420 aero

Sapim cx ray

Spoke Count

28

Spoke Length Non-Drive Side

290mm

Spoke Pattern Non-Drive Side

4 x cross

Spoke Pattern Drive

4 x cross

Spoke Length Drive

288mm

Max Tire Pressure

60psi

Max Tire Pressure

4bars

11-speed compatible

Yes

Track Adaptable

No

Brake Surface

n/a

Nipples

Taiwan CN® alloy nipple

External Nipples

Yes

Hub Compatible

SHlMANO 9/10/11s

Sram XD

If you decide to purchase,

please choose from the following order spec template and leave a message to us.

WEAVE:3K or UD

FINISHING:Matte or Glossy

Hub O.L.D:Front 9mm qr / 12x100 axle / 15x100 /15x110 boost

Rear 10mm qr/ 12x135 axle/ 12x142 / 12x148 boost

Hub compatible:SHlMANO 9/10/11s or Sram XX1

Pillar PSR X-TRA 1420 spokes , super light at 4.3g/pcs(260mm)

Detailed Pictures

Shipping and Delivery

We ship to worldwide countries, via EMS/DHL/China Post Air Parcel.

China Post Air Parcel will take15-30business days.

EMS reach most of the countries in7 to 20business days.

Delivery time depends on destination and other factors,China Post Air Parcel and EMS may takes up to60business days;

DHL usually takes2-7business days, and it may take up to12business days because of the destination and other factors;

For some European country , we recommend XDB express.

PlsNOTE:

We are not responsible for:

(1)Compensating you for payment of any import or value added taxes caused by your countries

(2)Products seized by your local customs.We can't control any option or right that customs holds.

(3)Any delays, accidents or any other issues incurred by the shipping companies or the weather.

Warranty

We provide2-year-warrantyfor our carbon rims.

If there are any manufacturing defects found, we are responsible to do replacement within 30 days

without any extra cost collected.

However, the warranty does not cover:

Normal wear  of braking surface/pads/bearings and pawls in the hub and improper assembly or follow up maintenance,

damage or failures caused by a crash, impact, abuse of the product,

non-compliance with manufactures specifications of usage or any other fractious reasons;

When the serial number or production code has been deliberately altered, defaced or removed.
