China Professional Car Paint Oven Electric Heat Spray Booth With Different Models |

Product details:

NOTE: Product is heavy and volumn is big, So we can not send you by express, if you interest it, please tell us your city or your nearest port, we will send you by sea, train, or truck to your place, when goods arrived receipt place, Please help to clear the customs. We will provide full export documents, manual, installation instructions and so on

Product Description

The car paint booth is generally painted and baked. Therefore, the exact description of the paint booth should be “auto paint booth paint room”. The air control of the paint booth can save the space and is convenient to use. At the same time, the primer and top coat can be applied. Forced drying and speeding up the work cycle improve work efficiency and layer quality.

Running operation /Easy to use/Easy to maintain

The equipment is reliable in operation, simple in operation and convenient in maintenance. At the same time, it fully considers the safety of equipment operation, and adopts reliable control methods in temperature control and time to ensure the overall performance and development of the equipment.

Reinforced sheet

It adopts sturdy sheet shape, beautiful thermal insulation performance, good steel stability, good impact resistance and quick prefabrication.

Product Features

Provide a good coating environment. The paint booth provides a good coating environment when painting. At the same time, it treats the paint mist. The waste and paint baking paint and paint are carried out in the same room. The paint is the paint on the surface of the workpiece. Curing at a certain temperature

Good working environment

In order to keep the air in the paint booth clean, all kinds of paint booths are equipped with filter devices, such as filter cotton, to filter the dust entering the air in the paint booth, and the ventilation system of the paint booth will make the paint There is enough ventilation in the room to ensure the air in the paint booth is clean.



Booth Outside: 7000*4000*3150mm   Booth Inside:6900*3900*2600mm   Dimension of Entrance Door:2500*2950mm   Personnel Door:750*1800mm   Noise≤75db   Working temperature≤60 degree   Rate of temperature increase:3-5min(20-60 degree)   Power consumption≤ 24kw/h   Walls & Ceiling: Panels 75 mm thick, with foam in the middle and color steel on both sides   Inlet Fan: air capacity 24000m⊃3;/h   Exhaust Fan: air capacity 12000m⊃3;/h   illuminance: 800 lux   Air filter efficiency: >98%   Heating method: Far infrared electric heating  ​
