CG Pro 9S12 Features:

Support for Freescale 705 series
Support for Freescale 908 series
Support for Freescale 711 series
Support for Freescale 912 series
Support for Freescale 9S12 series
Support NEC V850 series
Supports engine computer change and ISN read
Support automatic conversion for B*M*W, for mb kilometers
Support for B*M*W, for LandRover, for apor*sche key programming

CG Pro 9S12 Flash point:

Support a variety of strong encryption chip crack, stable fast
Software equipment using high-end technology, real-time monitoring, anti-loss
This programmer is complementary to the CG-100
With independent intellectual property rights, arbitrarily increase the chip model according to customer demand.

CG Pro 9S12 Highlights:

Read and write any for B*M*W, CAS 1-4, for apor*sche BCM, for MB EIS, for A*U*D*I BCM2 Etc anti-
theft computer (100% stable security, subject to domestic test users alike)

CG Pro 9S12 Support ECU IMMO List:

for B*M*W,:
CAS4+     5M48H/1N35H    (9S12XEP100)
CAS4    1L15Y    (9S12XDP512)
CAS3    0L15Y/0M23S    (9S12XDP512 including CAS3+ series）
CAS3    0L01Y    (9S12DG256)
CAS2    0L01Y/2K79X    (9S12DG256)
CAS2/E66    0L01Y/2K79X    (9S12DG256)
CAS1    0K50E    (912DT128A Write FLASH data online）
EWS4    0L86D/1L86D/2L86D    (9S12DJ64)
EWS3    0D46J/2D47J    (MC68HC711EA9)
EWS2    1D47J    (MC68HC711EA9)
(Support read/write data above for mileage correction and immobilizer reset )

for MB:
EIS   211  ST12 3L40K/1L59W/4L40K/1L85D/0L85D/2L85D/
EIS   211  HC12  0K50E/3K91D
EIS   209  ST12   3L40K/1L59W/4L40K/1L85D/0L85D/2L85D/
EIS  209  HC12  0K50E/3K91D
EIS   215  ST12   3L40K/1L59W/4L40K/1L85D/0L85D/2L85D/
EIS   215  HC08  2J74Y/4J74Y/1J35D(Can directly reset EIS data with 08 adapter;and read write EEPROM without extra adapter）
EIS    220     HC05  0D53J/0D59J/0D62J/0D69J/0F62J/0F82B/0G47G/0H51A/1D59J/1D69J/1H52A/2D20J/2D59J
EIS   210     HC05   0D53J/0D59J/0D62J/0D69J/0F62J/0F82B/0G47G/0H51A/1D59J/1D69J/1H52A/2D20J/2D59J
EIS      203  HC08  1J35D/2J74Y/4J74Y
EIS       164  ST12   3L40K/4L40K/1L59W/0L85D/1L85D/2L85D
EIS       169  ST12   3L40K/4L40K/1L59W/0L85D/1L85D/2L85D
EIS       639  ST12   0L01Y
EIS      639  HC08  0L02M/1L02M/4J74Y/1J35D/2J74Y
EIS       199  ST12   3L40K/4L40K/1L59W/0L85D/1L85D/2L85D
EIS       230  ST12   3L40K/4L40K/1L59W/0L85D/1L85D/2L85D
(Support all above data read/write for mileage correction and immobilizer reset)

for Roe*we:
750 IMMO   0M89C  (Read/Write)

for LandRover:
EWS  ST12   3L40K/4L40K/5L40K
RFA   9S12XEQ384      (1M12S 2M12S 1M53J 2M53J ) 9S12XET512  ( 3M53J  2M53J 1M53J)

Support Dash Type:

for MB
for B*M*W
for Domestic cars 9S12 dash
for LandRover
for Mini

for A*U*D*I:
for A*U*D*I        A4/A5/Q5-BCM      NEC               D70F3634/D70F3380
for A*U*D*I      ELV      HC08GR        4L35K

Key Programming:

for  CAS3             YES
for  CAS3+           YES
for CAS4            YES
for CAS4+           YES
for  EWS4
for EWS3
for EWS2
for apor*sche 911               BCM              YES
for apor*scheBoxster        BCM              YES
for apor*scheCayman       BCM              YES
for apor*schePanamera        BCM          YES
for apor*scheCayenne          BCM          YES
for apor*scheMacan             BCM           YES
(Program key via eeprom data）

Support Chip List:

for Mi-crocontroller:
for Motorola:
9S12 series:
9S12XDP512-0L15Y
9S12XDP512-1L15Y
9S12XDP512-0M23S
9S12XEP100-1N35H
9S12XEP100-5M48H
9S12XEx512-2M25J
9S12XEx512-3M25J
9S12D64-2L86D
9S12DJ64-0M89C
9S12DT128-1L59W
9S12DT128-4L40K
9S12DT128-1L85D
9S12DG128-3L40K
9S12DG256-0L01Y(CAS)
9S12DG256-2K79X
9S12XHZ384-1M80F

HC912 serie:
HC912DG128-0K50E
HC912DG128A-0L05H
HC912DG128A-3K91D

HC908 series:
HC908AZ60-4J74Y
HC908AZ60-1J35D
HC908GR16-4L35K

HC711 series:
HC711EA9-2D47J

HC705 series:
HC705-0D69J
HC705-0D53J

NEC:
D70F3634
D70F3380

CPU:
ST:
35080DQ
35160DQ
35080_3/6
35080VP/V6

8-foot chip:
24C01    24C02    24C04    24C08    24C16    24C32    24C64    24C128    24C256    24C01A    24C01B
24C02B    24LC01A    24LC01    24LC02    24LC04    24LC16    24LC32    25010    25020    25040    25080
25160    25320    25640    25128    25256    93C46    93C56    93C66    93C57    93C76    93C86
93A86    93CS56    93CS66    93S56    93LC46    93LC56    93LC66    93LC76    93LC86    95010    95020
95040    95080    95160    95320    95640    95128    95256

AMD:
AM29BL802CB
AM29F200
AM29F400
AM29F800
