36V 48V 52V 10 4ah 13ah 16Ah 20ah 21ah ebike water bottle Battery 750W 1000W motor electric bike with 30A BMS | Спорт и развлечения

36V 48V 52V 10 4ah 13ah 16Ah 20ah 21ah ebike water bottle Battery 750W 1000W motor electric bike with 30A BMS | Спорт и развлечения

36v 48v 750w 1000W motor water bottle dolphin li-ion battery for Ebike battery 10ah 12ah 15ah 20ah

Battery Suitable Motor power 750w 1000W

fat bike mountain bike city bike Electric Bike battery pack

Lithium ion E-bike battery Suitable Gear motor, Gearless motor, Brushless DC motor etc

Suitable bafang motor, Tongsheng motor, Golden motor etc

Folding bike city bike mountain bike

Bottle dolphin ebike battery

Specification

Model 24v 36v 48v bottle dolphin type

Nominal Voltage 24v 36v 48v

Nominal Capacity 10ah 12ah 15ah 16ah 17.5ah 20ah

Weight Approx2.5-4.4kg

Battery color Silver color (optional black color, please leave message)

Sutiable motor 250W 350W 500W 750w 1000W

Battery Dimension Customize size optional

Standard Charge 2A-3A

Fast Charge 3A/4A/5A

Standard Discharge 10A-20A

BMS 30A continuous 90A Peak (Optional Customize depends on motor)

BMS function Over-Current Protection,Over-Discharge Protection, Over-Charge Protection,Short-Circuit Protection, Balance

Charger 3A charger input plug provide match differrent countries

Parts included:

1. Lithium Battery

2. Built-in 30A BMS board

3. 42V/54.6v/58.8V 2.0a Charger (With EU/US/UK/AU Adapter you can choose)

Electric Bike Battery Pack

36V 13Ah Specification:
Nomal Volt: 36V
Rated Capacity:13AH
Battery Cell:Built in 2600mah.50PCS
Array mode:10s5p
Battery size:about L360*D90mm
Battery Weight:3.5KG
Max Constant Discharge Current:30A
Peak current:60A
Charge voltage:42V
Discharge cut off voltage:28V
Way of Charge:CC/CV
Cycle Life:1000 tims
Charge Temperature:-15-65℃
Discharge Temperature:-15-65℃
Protection Function:Over charge, Over discharge,Over current, Short circuit, Balance

36V 16Ah Specification:
Nomal Volt: 36V
Rated Capacity:16AH
Battery Cell:Built in 2600mah.60PCS
Array mode:10s6p
Battery size:about L380*D90mm
Battery Weight:4.1KG
Max Constant Discharge Current:30A
Peak current:60A
Charge voltage:42V
Discharge cut off voltage:28V
Way of Charge:CC/CV
Cycle Life:1000 tims
Charge Temperature:-15-65℃
Discharge Temperature:-15-65℃
Protection Function:Over charge, Over discharge,Over current, Short circuit, Balance



36V 21Ah Specification:
Normal Voltage: 36V
Rated Capacity:20.4AH
Battery Cell:Built in 3400mah.60PCS
Array mode:13s6p
Battery size:about L380*D90mm
Battery Weight:about 4.2KG
Max Constant Discharge Current:30A
Peak current:60A
Charge voltage:42V
Discharge cut off voltage:28V
Way of Charge:CC/CV
Cycle Life:1000 times
Charge Temperature:-15-65℃
Discharge Temperature:-15-65℃
Protection Function:Over charge, Over discharge,Over current, Short circuit, Balance



48V 10.4Ah Specification:
Normal Voltage: 48V
Rated Capacity:10.4AH
Battery Cell:Built in 2600mah cells.52PCS
Array mode:13s4p
Battery size:about L380*D90mm
Battery Weight:4.1KG
Max Constant Discharge Current:30A
Peak current:60A
Charge voltage:54.6V
Discharge cut off voltage:36.4V
Way of Charge:CC/CV
Cycle Life:1000 times
Charge Temperature:-15-65℃
Discharge Temperature:-15-65℃
Protection Function:Over charge, Over discharge,Over current, Short circuit,Balance


48V 16Ah Specification:
Normal Voltage: 48V
Rated Capacity:16AH
Battery Cell:Built in 3200mah.65PCS
Array mode:13s5p
Battery size:about L430*D90mm
Battery Weight:4.4KG
Max Constant Discharge Current:30A
Peak current:60A
Charge voltage:54.6V
Discharge cut off voltage:36.4V
Way of Charge:CC/CV
Cycle Life:1000 times
Charge Temperature:-15-65℃
Discharge Temperature:-15-65℃
Protection Function:Over charge, Over discharge,Over current, Short circuit, Balance



52V 10.4Ah Specification:
Normal Voltage: 52V
Rated Capacity:10.4AH
Battery Cell:Built in 2600mah.56PCS
Array mode:14s4p
Battery size:about L380*D90mm
Battery Weight:4.1KG
Max Constant Discharge Current:20A
Peak current:60A
Charge voltage:58.8V
Discharge cut off voltage:39V
Way of Charge:CC/CV
Cycle Life:1000 times
Charge Temperature:-15-65℃
Discharge Temperature:-15-65℃
Protection Function:Over charge, Over discharge,Over current, Short circuit,Balance


52V 13Ah Specification:
Normal Voltage: 52V
Rated Capacity:12.8AH
Battery Cell:Built in 3200mah.56PCS
Array mode:14s4p
Battery size:about L380*D90mm
Battery Weight:4.4KG
Max Constant Discharge Current:20A
Peak current:60A
Charge voltage:58.8V
Discharge cut off voltage:39V
Way of Charge:CC/CV
Cycle Life:1000 times
Charge Temperature:-15-65℃
Discharge Temperature:-15-65℃
Protection Function:Over charge, Over discharge,Over current, Short circuit, Balance
