Description:

From the center hole the hour hand is 90mm, the minute hand 120mm, the second hand 120mm, used for the wall clock with a plate diameter of 250-330 mm.
Size: total length of the shaft: 14mm, thread length: 6.7mm jumping the second set, suitable for 4mm thickness clock panel. The pointer length can be cut with scissors to the desired size.
Long spindle watch movement spare parts with metal hook, it can be hung directly on the wall via nail.
Suitable for repair, replacement or to make a clock, replacement for big and thick clock frame.
It is a kind of clock movement that will receive radio waves and is automatically timed, which can automatically correct the time error.

Specification:

Material: Metal, copper, aluminum
Size: 56x56x19mm
Model: HR9312+904
Radio clock core parameters:
Receiving Frequency:77.5KHz
Battery Size: AA/LR6（Alkaline）
Battery Life: ≥1 Year
Operating Voltange: 1.25-1.7V
Quartz Accuracy（AT25℃）:±1s/d
Operating Temperature: -5℃-+55℃
Storage Temperature: -20℃-+70℃
Current Consumption（1.5V）:＜150μA
Receiving Time: 3-8min
Receining Current: ＜100μA
Setting Time After Reception: max.4min
Operating Noise:＜32dB
Antenna: Ferrite core intefnal
Reception: 12x/day
Peak Current: 7mA
Sensitivity: ＜80μV/m
Second Hand Torque（1.5v）: ≥180μNm

Package Includes:

1 Piece Quartz Clock
1 Piece Hour Hand
1 Piece Minute Hand
1 Piece Second hand
1 Piece Metal Hook
1 Piece Nut
1 Piece Rubber Mat
1 Piece Spring Washer
1 x Rubber Washer
1 Washer

Note:

The Battery is not included.
