HIFI TPA3116 2.1 NE5532 Subwoofer Class D Power amplifier 2*50W+100W With Bluetooth 4.2 50W*2+100W | Электроника

HIFI TPA3116 2.1 NE5532 Subwoofer Class D Power amplifier 2*50W+100W With Bluetooth 4.2 50W*2+100W | Электроника

Product details:

● Use original TPA3116, NE5532With Bluetooth 4.2

● The precision SMT resistor is used to ensure a good signal-to-noise ratio of the whole machine.

● The PCB adopts 1.6mm thick double-sided sheet, 2.0 oz copper thickness, and the whole process of tin-spraying ensures the good passing performance of the current. First-class PCB quality.

● With fully enclosed dust-proof potentiometer, the performance is more stable and more durable than ordinary potentiometers!

● The red-grey ring audio special high-current inductor is used to ensure the sound is crisp and powerful.

● It adopts full aluminum chassis, and all the surface of the chassis is processed by wire drawing oxidation coloring process!

● Bluetooth is connected in the same way as a normal device.

Input method: analog and Bluetooth input function.When two modes are input at the same time, the Bluetooth input is prioritized. After the Bluetooth connection, the RCA input is automatically disconnected; when the analog input is required, please turn off the Bluetooth function of the mobile phone before switching.

Basic parameters:

Working method: Class D

Quiescent current: 50mA

Work efficiency: 90%

Output power: 2*50W+1*100W

Frequency response: 20Hz to 20KHz

Working voltage: DC 18V---24V

Maximum output current: 2A

DC plug size: External 5.5mm * internal 2.1mm)

Potentiometer function: From left to right (Left and right channel treble adjustment, left and right channel bass adjustment, subwoofer volume adjustment,Subwoofer frequency adjustment, total volume adjustment)

Size: 185mm*105mm*43mm

Weight: 0.7KG

The package includes:

TPA3116 2.1 Subwoofer Class D Power amplifierWith Bluetooth 4.2X1

NOTE：We do not include DC power adapter
